Description
Features & Benefits
- Better lumens & longer lamp life
- High efficacy & lower power consumption
- Delivers high brightness & excellent illumination
- No harmful UV & IR radiations
- Environment friendly as it does not contain Mercury
- Instant light with low running temperatures
- Operating temperature:-10° C to +50° C
- Operating voltage range: 140 -270 V
- Average life L70B50: 50000 hours
Housing
Aluminum alloy pressure die casted housing for better heat dissipation and aesthetic appeal.
Finish
The housing is epoxy powder coated with colour munshell grey finish.
Light source
High efficiency long life LEDs with lumen efficacy of >150 lm/W with view angle 120º to ensure better uniformity of light distribution. 5700K
Optics
High quality PC lens with optional narrow & wide beam angles for uniform distribution (For Detailed photometric data, please refer LM 79 report & IES file).
Cover
Tempered protective toughened glass, thermal shock and impact resistant fixed to the housing with SS screws.
Electronic driver
Buit In, electronic driver with APFC, lower THD, Open Circuit Protection, Surge Voltage Protection upto 10 kV with Built In SPD & other safety test as per IS 15885 Part-2/ Sec 13.
Mounting
Suspended by means of heavy duty nickel plated, forged eye-bolt provided with the fixture.
Applications
- Cement & steel plants
- Ware houses
- Factories & assembly lines
- Toll plazas
